My Modular Layout.

[Smudge617]

Due to circumstances beyond my control, the previous PIR-fect layout is no more, so I'm starting a new layout using a supposedly modular design, not that description fits I don't think, but here goes anyway.

Layout Plan (Ignore colour coding, I got bored)

Layout Size 9" x 5' (Split into 2 x 4'6" X 5' modules.
Lumber to be used 2" X 3" for framework
Legs will 6 X 2" x 2" x 35"
Layout board 6mm Plywood.

We rarely find Plywood in the UK larger than 8' x 5' unless it's a special order, and that makes it expensive, so the board will be made of
2 x 5' x 4' sheets
4 x 6" x 2' 6" rips.



[RhB Michael]

Is that a slip at the bottom inner yard lead track heading to the right? If not, it might be worth thinking about. It would give you more routing options.



[Smudge617]

Is that a slip at the bottom inner yard lead track heading to the right? If not, it might be worth thinking about. It would give you more routing options.

Top right will be a double crossover .with a single slip in/out the reverse loop
